Case Construction Equipment has created an all-new purpose-built landfill configuration for its 2050M dozer, providing enhancements and guarding that make it suitable for work in harsh landfill environments.

The specialized design was tested and refined in large-scale landfill operations throughout North America in advance of the launch.

“Our product specialists, and each test site, spent considerable time monitoring machine performance and guarding,” said Nathaniel Waldschmidt, product marketing manager for Case Construction Equipment.

“Additional enhancements have been made, and what we’re coming to market with now is a powerful landfill dozer that will provide extreme performance and productivity, as well as protection from the unique working conditions of a landfill.”

The Case 2050M is the manufacturer’s most powerful dozer, operating at a rated 214 net horsepower with a drawbar pull of 36731 kg. The new configuration features extensive guarding and systems to keep the dozer working efficiently in large-scale landfill operations.

A new wide-track- or low-ground-pressure-track-configured bulldozer semi-u blade with trash rack increases blade capacity to 11 cubic metres, with an overall height of 2 metres.

The height allows significant material carrying capacity, which takes advantage of the 2050M’s industry-leading drawbar pull in its horsepower class. As well, the dozer is available with an optional 6-way PAT blade configuration with the same high material carrying capacity trash rack.

To prevent trash buildup, the dozer is equipped with new tank guards and debris deflectors that redirect material away from the chassis and protects the engine, cooling package, tanks, and other critical components of the dozer. Furthermore, a chassis seal kit, built from plate steel, covers gaps and prevent trash buildup.

The purpose-built dozer is also equipped with:

The 2050M features primary operating systems and components suited for working in landfills. In addition to the robust drawbar pull, the dozer features a hydrostatic drive system that reduces parasitic drag on the engine and allows the machine to put more horsepower and torque to working efforts.

An advanced load management system automatically reduces track speed (increasing torque) with a heavier load on the blade, and increases track speed (reducing torque) with a lighter load on the blade, ensuring the machine is working at optimal power. The system provides 100 per cent power to a turning track, while also allowing inside tracks to maintain pushing power.

RELATED: A shared approached to solid waste management

The Case 2050M meets EPA Tier 4 Final emissions regulations with Selective Catalytic Reduction (SCR) technology, which also helps keep temperatures down in the engine compartment, and contributes to greater power and fuel efficiency as the engine is not using diesel/effort to burn off accumulated particulate through regeneration.

As well, the dozer features a cooling system tested under maintained heavy load conditions and is designed to optimize engine and hydraulic temperatures.

The 2050M features control customizations that allow the operator to tailor machine performance and responsiveness to their preferences, including the ability to set blade sensitivity, steering sensitivity and shuttle sensitivity to smooth, moderate or aggressive.

An electro-hydraulic joystick further simplifies operation by providing better feel and responsiveness to the operator, and fingertip blade shake allows for quick shedding of accumulated trash.

 The 2050M also features a sealed and pressurized cab that helps keep dust and other materials out of the operating environment.

Noise is reduced down to 75 dBa compared to previous Case dozers, and amenities such as a factory-installed radio and environmental controls further make the 2050M the most comfortable Case dozer cab ever built.
